C11 _Atomic lock‑free counter guide

Learn how to declare, initialize, and use a C11 _Atomic integer as a lock‑free counter, with compile commands, verification steps, and fallback options.

Desired outcome

Create a shared integer that can be safely incremented by any number of threads without using a mutex, relying on hardware‑supported atomic operations provided by the C11 _Atomic qualifier (or <stdatomic.h> types).

Prerequisites

A compiler that implements C11 atomics (GCC 4.9+, Clang 3.1+, MSVC 2015+).
Target architecture that supplies lock‑free atomic integer instructions (most x86‑64, ARMv8, etc.).
Basic knowledge of creating and joining POSIX threads (pthread).
Access to a terminal with normal user privileges; no special permissions are required to compile or run the test program.

Focused procedure

Declare the atomic counter.
```
#include <stdatomic.h>
#include <pthread.h>

static atomic_int counter = ATOMIC_VAR_INIT(0);
```
The variable counter is of type atomic_int, which guarantees that reads and writes are indivisible.

Initialize (if not using ATOMIC_VAR_INIT).

For dynamic allocation you can use:

atomic_int *counter = malloc(sizeof *counter);
if (counter) atomic_init(counter, 0);

Define the increment operation.

Use atomic_fetch_add_explicit with a memory order that matches your needs. For a simple counter where only the final value matters, memory_order_relaxed is sufficient:

static void *worker(void *arg)
{
    int iterations = *(int *)arg;
    for (int i = 0; i < iterations; ++i)
        atomic_fetch_add_explicit(&counter, 1, memory_order_relaxed);
    return NULL;
}

Start threads and join them.

#define N_THREADS 8
#define INCREMENTS_PER_THREAD 1000000

int main(void)
{
    pthread_t threads[N_THREADS];
    int arg = INCREMENTS_PER_THREAD;
    for (int t = 0; t < N_THREADS; ++t)
        pthread_create(&threads[t], NULL, worker, &arg);
    for (int t = 0; t < N_THREADS; ++t)
        pthread_join(threads[t], NULL);
    int final = atomic_load_explicit(&counter, memory_order_acquire);
    printf("Final counter value: %d\n", final);
    return 0;
}

Compile the program.
Run the following command in your project directory:
```
gcc -std=c11 -O2 -Wall counter.c -lpthread -o counter
```
Replace gcc with clang or your preferred compiler if needed.
Execute and verify correctness.
```
./counter
```
Expected output (with the constants above):
```
Final counter value: 8000000
```
If the printed value equals N_THREADS × INCREMENTS_PER_THREAD, the counter behaved correctly.

Expected checks

Lock‑free status. At runtime you can query:
```
printf("counter is lock‑free: %d\n", atomic_is_lock_free(&counter));
```
A return value of 2 means the operation is always lock‑free on this platform.
Assembly inspection. To confirm the compiler emitted a single atomic instruction:
```
objdump -S counter | grep -A2 ":"
```
Look for something like lock xadd on x86‑64, which indicates a hardware fetch‑add.
ThreadSanitizer. Build with -fsanitize=thread and run; no data‑race warnings should appear for the atomic counter.
```
gcc -std=c11 -O2 -fsanitize=thread counter.c -lpthread -o counter_tsan
./counter_tsan
```

Limitations and recovery options

If atomic_is_lock_free(&counter) returns 0, the implementation falls back to a mutex internally, eliminating the lock‑free advantage. In that case you can:
- Use a explicit pthread_mutex_t around a plain integer (still correct, just slower).
- Fall back to GCC built‑ins like __sync_fetch_and_add if you need a portable lock‑free primitive on older toolchains.
Using memory_order_relaxed for increments means other threads may observe stale values if they rely on the counter for ordering. When ordering matters (e.g., a flag that signals completion), replace the increment with memory_order_release and the read with memory_order_acquire, or use memory_order_seq_cst for simplest reasoning.
The counter only guarantees atomicity for a single variable. Multi‑variable invariants still require additional synchronization (mutexes, condition variables, etc.).

Practical way to check the result

After running the stress test, compare the final value with the expected product. A simple script can automate the check:

#!/bin/bash
EXPECTED=$((N_THREADS * INCREMENTS_PER_THREAD))
ACTUAL=$(./counter | grep -o '[0-9]\+')
if [ "$ACTUAL" -eq "$EXPECTED" ]; then
    echo "PASS"
else
    echo "FAIL: expected $EXPECTED, got $ACTUAL"
    exit 1
fi

Run the script; a non‑zero exit indicates a problem that warrants reviewing compiler flags, memory order, or platform support.
