Building a Custom Block in Sulu CMS: From Zone Configuration to Frontend Rendering

Problem: Adding a Reusable Callout Without Touching Templates

You need a styled callout box that editors can drop into any page zone, but you don’t want to edit Twig layouts each time a new callout is required. The goal is to let administrators add the component through the Sulu admin UI while keeping the frontend rendering consistent.

Takeaway

By defining a custom block class and a Twig template, you can make the callout available as a draggable block in any zone. The three‑tier hierarchy (Page → Zone → Block) handles storage, rendering, and inheritance automatically.

Understanding the Page‑Zone‑Block Hierarchy

Sulu stores content in three related tables:

• sulu_page – represents each node in the page tree.
• sulu_zone – belongs to a page and defines a named layout area (e.g., "main", "sidebar").
• sulu_block – belongs to a zone and holds the serialized data of a specific block type.

When a page is rendered, Sulu loads its zones, then instantiates each block’s PHP class and passes the block’s data to the corresponding Twig template.

Creating a Custom Callout Block

1. Create the PHP block class

   Place the class in src/Block/CalloutBlock.php. It must extend Sulu\Bundle\BlockBundle\Block\BlockInterface or use the provided abstract base.

   <?php

   namespace App\Block;

   use Sulu\Bundle\BlockBundle\Block\BlockInterface;
   use Sulu\Bundle\BlockBundle\Block\BaseBlock;

   class CalloutBlock extends BaseBlock implements BlockInterface
   {
       public function getName(): string
       {
           return 'callout';
       }

       public function getTemplate(): string
       {
           return '@App/block/callout.html.twig';
       }

       public function getViews(): array
       {
           return [
               'default' => [
                   'title' => 'Callout',
                   'icon' => 'comment',
                   'properties' => [
                       ['name' => 'title', 'type' => 'text'],
                       ['name' => 'content', 'type' => 'html'],
                   ],
               ],
           ];
       }
   }


   Required permissions: the web‑server user must be able to read the src/ directory. No database changes are made yet.

2. Add the Twig template

   Create templates/block/callout.html.twig:

   {# templates/block/callout.html.twig #}


   {{ block.title|default('Callout') }}

           {{ block.content|raw }}




   Make sure the template directory is registered in your Symfony framework.templating.paths if you are not using the default templates/ location.

3. Register the block with Sulu

   Add a sulu_block.xml file in config/packages/ (or extend an existing one):

   <?xml version="1.0" ?>
   <container xmlns="http://symfony.com/schema/dic/services"
       xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
       xmlns:sulu="http://sulu.io/schema/dic/sulu"
       xsi:schemaLocation="http://symfony.com/schema/dic/services http://symfony.com/schema/dic/services/services-1.0.xsd
                           http://sulu.io/schema/dic/sulu http://sulu.io/schema/dic/sulu/sulu-1.0.xsd">

       <sulu:block>
           <sulu:block-type>App\Block\CalloutBlock</sulu:block-type>
       </sulu:block>
   </container>


   After adding the file, clear the cache:

   # Run as the application user (e.g., www-data)
   php bin/console cache:clear --env=prod


   Risk: clearing the prod cache will briefly serve stale responses; schedule during low‑traffic periods or use Symfony’s warm‑up command.

4. Make the block available in a zone

   In the Sulu admin, edit a page, click the “Zones” tab, choose a zone (e.g., “main”), and drag the newly appeared “Callout” block into the zone. Fill the title and content fields, then save.

Trade‑offs and Limitations

• Performance: Deeply nested zones (zones inside zones inside zones) increase the number of Doctrine queries and Twig renders. Keep the hierarchy shallow (Page → Zone → Block) for predictable latency.
• UI Consistency: Because administrators can place any block in any zone, a design system or governance policy is needed to prevent layout clashes.
• Version Assumptions: The example assumes Sulu 2.x (Symfony 5+). The block interface and XML configuration have remained stable since Sulu 2.0.

Verification

1. Open the Sulu admin, navigate to a page, and confirm the “Callout” block appears in the zone’s block picker.
2. Save the page and view the frontend; inspect the rendered HTML for the <div class="callout"> wrapper.
3. Optionally, check the database: SELECT * FROM sulu_block WHERE block_type = 'App\\Block\\CalloutBlock'; should return a row with the saved title and content serialized in the data column.

Closing

Defining a custom block in Sulu gives editors a reusable, drag‑and‑drop component while keeping the rendering logic in a single Twig template. By respecting the Page‑Zone‑Block hierarchy and watching for nesting depth, you maintain both flexibility and predictable performance.
