Building a Cross‑Platform Login Screen with Alloy MVC in Titanium

Desired Outcome

Produce a single Alloy project that displays a native‑looking login screen on both iOS and Android, performs an asynchronous POST to a REST endpoint, stores the returned token in the app sandbox, and, on Android, opens the device camera via a native intent.

Prerequisites

• Node.js 18+ and npm installed.
• Appcelerator Titanium SDK 10.x (or newer) and Alloy CLI.
• Xcode 15+ for iOS builds and Android Studio 2024+ for Android builds.
• Basic knowledge of JavaScript and XML.
• Access to a test REST server that accepts JSON and returns a token.

Project Setup

1. Create a new Alloy project:

   titanium create -t appcelerator -n loginDemo

2. Navigate into the project folder:

   cd loginDemo

3. Add the Android platform for intent testing:

   titanium platform add android

Define the Platform‑Specific View

Alloy’s <View> component maps to the native UI widget for the current platform. Use <If> blocks to tweak properties that differ between iOS and Android.

<Alloy>
  <Window title="Login" layout="vertical" backgroundColor="#fff">
    <View height="50dp" width="300dp" backgroundColor="#e0e0e0">
      <TextField id="username" hintText="Username" color="#000"/>
    </View>
    <View height="50dp" width="300dp" backgroundColor="#e0e0e0">
      <TextField id="password" hintText="Password" passwordMask="true" color="#000"/>
    </View>
    <Button id="loginBtn" title="Login"/>
    <If platform="android">
      <Button id="cameraBtn" title="Open Camera (Android)"/>
    </If>
  </Window>
</Alloy>

Explanation of terms:

• <If platform="android"> renders its children only on Android.
• TextField is the native text input; passwordMask hides input characters.
• The loginBtn will trigger the network request.

Centralized Styling with TSS

Alloy’s TSS (Ti Style Sheets) lets you write CSS‑like rules that compile to native properties. Create app/styles/alloy.tss:

$.username, $.password {
  left: 20dp;
  right: 20dp;
  top: 10dp;
}
$.loginBtn {
  top: 20dp;
  width: 200dp;
  backgroundColor: #3f51b5;
  color: #fff;
}
$.cameraBtn {
  top: 10dp;
  width: 200dp;
  backgroundColor: #f44336;
  color: #fff;
}

Controller Logic

The login.js controller wires UI events, performs the network call, and handles file storage.

function login() {
  var client = Ti.Network.createHTTPClient({
    timeout: 5000,
    onload: function(e) {
      try {
        var response = JSON.parse(this.responseText);
        if (response.token) {
          Ti.Filesystem.getFile(Ti.Filesystem.applicationDataDirectory, 'token.txt').write(response.token);
          alert('Login successful! Token stored.');
        } else {
          alert('Login failed: no token received.');
        }
      } catch (ex) {
        alert('JSON parse error: ' + ex.message);
      }
    },
    onerror: function(e) {
      alert('Network error: ' + e.error);
    }
  });

  client.open('POST', 'https://example.com/api/login');
  var payload = {
    username: $.username.value,
    password: $.password.value
  };
  client.send(JSON.stringify(payload));
}

$.loginBtn.addEventListener('click', login);

// Android‑only: open camera intent
if (OS_ANDROID) {
  $.cameraBtn.addEventListener('click', function() {
    var intent = Ti.Android.createIntent({
      action: Ti.Android.ACTION_IMAGE_CAPTURE
    });
    Ti.Android.currentActivity.startActivity(intent);
  });
}

$.index.open();

Key points:

• Ti.Network.createHTTPClient handles asynchronous GET/POST. The onload callback receives this.responseText.
• JSON parsing is wrapped in try/catch to avoid crashes on malformed responses.
• Token is written to applicationDataDirectory, which is sandboxed and persists across app launches.
• The Android intent uses Ti.Android.createIntent with ACTION_IMAGE_CAPTURE to launch the device camera.

Expected Checks

1. Build and run on an iOS simulator: verify the login screen shows, the button triggers a network call, and the token file appears in Documents.
2. Build and run on an Android emulator: confirm the camera button appears and opens the camera app.
3. Check console logs for Ti.Network events; use Xcode Debugger or Android Studio Logcat to trace native API calls.
4. Open the sandbox directory via ti run -p ios -T simulator -d and inspect token.txt.

Recovery & Rollback Options

• If the login button does not fire the network call, add Ti.API.debug('login clicked'); before login() to confirm event binding.
• When the Android intent fails (e.g., no camera), check for the android.permission.CAMERA permission in tiapp.xml and add it if missing.
• To revert UI changes, comment out the <If platform="android"> block and rebuild.
• Use ti clean to purge build caches if unexpected native files appear.

Limitations & Practical Tips

• Alloy XML does not expose every native property; for advanced features, switch to Ti.UI widgets in the controller.
• Large JSON payloads can stall low‑memory devices; consider using Ti.Network.createHTTPClient streaming or caching the response.
• Cross‑origin requests may be blocked by server CORS settings; ensure the API allows requests from your app’s domain.
• Always test on both platforms; platform differences can surface only at runtime.

Conclusion

By combining Alloy’s declarative XML, centralized TSS styling, and Titanium’s native APIs, you can build a clean, maintainable cross‑platform login flow that respects platform nuances. The example demonstrates how to keep UI logic in one place while gracefully handling platform‑specific behavior like Android intents and file storage.
