Build a Unified GraphQL API with Apollo Federation: A Step‑by‑Step Guide

Problem & Takeaway

When a single GraphQL endpoint grows too large, splitting it into micro‑services becomes inevitable. However, clients still expect a single schema. Apollo Federation solves this by allowing each service to expose entity types with @key directives, while an Apollo Gateway stitches them together at runtime. The result is a unified schema without sacrificing service autonomy.

Desired Outcome

• Two independent GraphQL subgraphs (User and Post services) each exposing @key directives.
• One Apollo Gateway that merges the subgraphs into a single schema.
• Verified entity resolution and introspection on the gateway.
• Optional caching enabled for improved latency.

Prerequisites

• Node.js 18+ installed on each service host.
• Basic knowledge of GraphQL SDL and resolver functions.
• Access to a network where the gateway can reach both subgraphs.
• Optional: Docker for containerized deployment.

Step 1: Create the User Subgraph

Define the User type with a unique @key field and expose _entities and _service for the gateway.

// user-service/index.js
const { ApolloServer, gql } = require('apollo-server');
const { buildFederatedSchema } = require('@apollo/federation');

const typeDefs = gql`
  type User @key(fields: "id") {
    id: ID!
    name: String
  }

  extend type Query {
    me: User
  }
`;

const resolvers = {
  Query: {
    me: () => ({ id: "1", name: "Alice" })
  },
  User: {
    __resolveReference: (obj) => ({ id: obj.id, name: "Alice" })
  }
};

const server = new ApolloServer({
  schema: buildFederatedSchema([{ typeDefs, resolvers }])
});

server.listen({ port: 4001 }).then(({ url }) => {
  console.log(`User subgraph ready at ${url}`);
});

Step 2: Create the Post Subgraph

The Post service references the User entity via @requires and declares its own @key directive.

// post-service/index.js
const { ApolloServer, gql } = require('apollo-server');
const { buildFederatedSchema } = require('@apollo/federation');

const typeDefs = gql`
  type Post @key(fields: "id") {
    id: ID!
    title: String
    author: User @requires(fields: "id")
  }

  type User @extends @key(fields: "id") {
    id: ID! @external
    name: String @external
  }

  extend type Query {
    posts: [Post]
  }
`;

const resolvers = {
  Query: {
    posts: () => ([{ id: "101", title: "Federation Rocks", author: { id: "1" } }])
  },
  Post: {
    author: (post) => ({ id: post.author.id })
  }
};

const server = new ApolloServer({
  schema: buildFederatedSchema([{ typeDefs, resolvers }])
});

server.listen({ port: 4002 }).then(({ url }) => {
  console.log(`Post subgraph ready at ${url}`);
});

Step 3: Configure the Apollo Gateway

The gateway pulls the subgraph schemas and exposes a single endpoint. It also handles entity resolution automatically.

// gateway/index.js
const { ApolloServer } = require('apollo-server');
const { ApolloGateway } = require('@apollo/gateway');

const gateway = new ApolloGateway({
  serviceList: [
    { name: 'user', url: 'http://localhost:4001/graphql' },
    { name: 'post', url: 'http://localhost:4002/graphql' }
  ],
  buildService: ({ name, url }) => {
    return new ApolloGateway({
      serviceList: [{ name, url }]
    });
  },
  // Enable caching for entity resolution
  cache: {
    type: 'in-memory',
    maxAge: 60
  }
});

const server = new ApolloServer({ gateway, subscriptions: false });

server.listen({ port: 4000 }).then(({ url }) => {
  console.log(`Gateway ready at ${url}`);
});

Step 4: Validate the Schema

Run an introspection query on the gateway to confirm that _entities and _service are present.

curl -X POST http://localhost:4000/graphql \
  -H "Content-Type: application/json" \
  -d '{"query":"{ __schema { types { name } } }"}'

Expected check: the response includes _entities and _service in the type list.

Sample Query Across Services

curl -X POST http://localhost:4000/graphql \
  -H "Content-Type: application/json" \
  -d '{"query":"{ posts { id title author { id name } } }"}'

Expected result: a list of posts with nested author data resolved through the gateway.

Performance Tuning: Enable Gateway Caching

When the gateway is under load, caching the _entities lookup reduces round‑trips to subgraphs.

// In gateway/index.js, adjust cache settings
const gateway = new ApolloGateway({
  serviceList: [...],
  cache: {
    type: 'in-memory',
    maxAge: 120, // seconds
    maxSize: 5000
  }
});

After deployment, monitor apollo_gateway_request_latency metrics or use a tool like wrk to compare latency before and after caching.

Troubleshooting & Recovery

• Runtime error: unresolved entity – Verify that all @key fields match across services and that the gateway can reach each subgraph.
• Missing _entities field – Ensure buildFederatedSchema is used and that the subgraph includes the _entities introspection resolver.
• Performance degradation – Enable gateway logs (debug level) to see where resolution stalls; consider increasing cache size or splitting hot paths into dedicated services.
• Gateway crash on startup – Check Node.js version compatibility and that all dependencies are installed. Run npm install in each service directory.

Limitations & Caveats

• Entity resolution errors surface only at runtime; static type checking cannot catch mismatched @key definitions.
• The gateway adds an extra hop; for very low‑latency use cases, consider a monolithic schema.
• Some GraphQL client libraries may not support the federation introspection queries; test with your client before production.
• Debugging distributed schemas requires inspecting logs from all services and the gateway.

Conclusion

Apollo Federation provides a pragmatic way to scale GraphQL services while keeping a single, discoverable schema. By following the steps above, you can deploy independent subgraphs, merge them with a gateway, validate entity resolution, and tune performance with caching. Regular introspection checks and monitoring will keep the federation healthy as services evolve.
