Bamboo Branch Builds: Automate CI for Every Feature Branch

Why Branch Builds Are a Game‑Changer

When every developer pushes a new feature branch, the classic CI workflow forces you to duplicate the entire Bamboo plan for that branch. You copy tasks, variables, and notifications, then tweak a few lines to point at the new branch. The result is a maintenance nightmare and a flood of build tabs that are hard to keep tidy.

Branch Builds solve this by letting Bamboo detect new branches automatically and spin up a separate build plan for each one. The new plan inherits all of the parent plan’s configuration, so you only need to tweak what’s different (for example, a different test suite). The build logs and artifacts are kept in a dedicated tab named after the branch, making troubleshooting straightforward.

Practical Setup – One Plan, Many Branches

Below is a step‑by‑step guide to enable Branch Builds on a Bamboo plan that uses a Git repository. The instructions assume Bamboo 6.0 or newer.

1. Navigate to the Plan Configuration
   • Open your Bamboo instance and go to Builds > Plans.
   • Select the plan you want to enable Branch Builds for.
2. Enable Branch Builds
   • In the plan configuration page, click the Branch builds tab.
   • Check Enable branch builds.
   • Choose the source control system (Git, Mercurial, or Subversion). For Git, provide the repository URL and authentication method.
   • Optional: set a Branch filter to include or exclude certain patterns.
   • Click Save.
3. Configure Webhooks
   • Navigate to the repository settings in Bamboo.
   • Under Repository hooks, add a webhook that triggers on push and pull request created events.
   • Copy the webhook URL and paste it into your Git hosting service (GitHub, Bitbucket, GitLab, etc.).
4. Verify the Setup
   • Push a new branch to the repository: git push origin feature/new‑feature.
   • Return to Bamboo – a new tab labeled feature/new‑feature should appear under the plan.
   • Click the tab to see the build run automatically.

Branch‑Specific Variables and Overrides

Branch Builds inherit all parent plan variables. If you need a variable to change per branch, you can define it in the branch tab. For example, suppose the parent plan runs a full test suite, but you want the feature/new‑feature branch to run only a subset of tests.

Parent plan variable:
  TEST_SUITE = full

Branch tab variable override:
  TEST_SUITE = subset

In the build tasks, reference the variable as ${bamboo.TEST_SUITE}. When Bamboo runs the branch build, it will resolve the overridden value.

Concrete Example – Deploy to Staging on Feature Branches

Assume you have a plan that builds a Java application and deploys to a staging environment. You want to deploy each feature branch to its own staging instance so that developers can test their changes in isolation.

1. Define a branch‑specific variable
   • In the branch tab for feature/awesome‑feature, add a variable:

     bamboo.stagingUrl = https://staging.awesome-feature.example.com

2. Modify the deployment task
   • In the plan’s deployment project, edit the deploy task to use the variable:

     Deploy to ${bamboo.stagingUrl}

3. Push the branch
   • After pushing feature/awesome‑feature, Bamboo automatically creates the branch build.
   • The build logs show the deployment URL resolved to the branch‑specific value.

Trade‑Offs and Limitations

• Agent Concurrency: Each branch build consumes an agent. If you have 5 agents and 10 branches, 5 builds run immediately while the rest queue. This can delay feedback for developers working on many branches simultaneously.
• Webhook Dependency: Automatic branch detection relies on correctly configured webhooks. If the webhook is missing or misconfigured, Bamboo will not create the branch build.
• Special Characters: Branch names with slashes or spaces may cause URL‑encoding issues in the Bamboo UI. Stick to alphanumeric characters, dashes, and underscores for branch names.
• Plan Size: Very large plans with many tasks can lead to long build times for each branch. Consider splitting complex pipelines into separate plans if performance becomes an issue.

How to Verify Your Branch Build Configuration

Use Bamboo’s REST API to list existing branch builds and confirm that new branches appear as expected.

curl -u username:password \
     -X GET \
     https://your-bamboo.example.com/rest/api/latest/branch-builds?planKey=PROJ-PLAN

Check the JSON response for an entry with branchName matching your recent push. Additionally, open the build tab and inspect the ${bamboo.branchName} variable in the logs to ensure it resolves correctly.

Bottom Line

Branch Builds let you maintain a single, clean Bamboo plan while still giving each feature branch its own isolated CI pipeline. By leveraging webhooks, branch‑specific variables, and the built‑in UI, you can provide rapid feedback to developers without the overhead of manual plan duplication. Keep an eye on agent availability and webhook configuration to avoid surprises, and use the REST API to audit your branch build inventory.
