Azure service tags overview for virtual network security

A service tag represents a group of IP address prefixes from a given Azure service. Microsoft manages the address prefixes encompassed by the service tag and automatically updates the service tag as addresses change, minimizing the complexity of frequent updates to network security rules.

Service tags simplify network security configuration in Azure by:

• Eliminating the need to manually track and update IP addresses for Azure services
• Providing automatic updates when Azure service IP ranges change
• Reducing the complexity of security rule management
• Enabling granular control over network traffic to and from Azure services

You can use service tags to define network access controls on network security groups, Azure Firewall, and user-defined routes. Use service tags in place of specific IP addresses when you create security rules and routes.

Important

While Service Tags simplify the ability to enable IP-based Access Control Lists (ACLs), Service Tags alone aren't sufficient to secure traffic without considering the nature of the service and the traffic it sends. For more information about IP based ACLs, see What is an IP based access control list (ACL)?.

Additional information about the nature of the traffic can be found later in this article for each service and their tag. It's important to ensure you're familiar with the traffic that you allow when utilizing service tags for IP based ACLs. Consider added levels of security to protect your environment.

How service tags work

When you specify a service tag name (such as ApiManagement) in the appropriate source or destination field of a security rule, you allow or deny the traffic for the corresponding service. The service tag automatically includes all current and future IP address ranges used by that service.

You can route traffic intended for any of the prefixes encapsulated by the service tag to a desired next hop type. Specify the service tag name in the address prefix of a route.

Common use cases

Service tags help you:

• Achieve network isolation: Protect your Azure resources from the general Internet while accessing Azure services that have public endpoints
• Simplify security rules: Create rules without managing individual IP addresses
• Ensure automatic updates: Stay current with Azure service IP ranges without manual intervention

For example, you can create inbound/outbound network security group rules that:

• Deny traffic to/from Internet
• Allow traffic to/from AzureCloud or other available service tags of specific Azure services

Open diagram: Screenshot of network isolation of Azure services using service tags.

Available service tags

The following table includes all the service tags available for use in network security group rules.

The columns indicate whether the tag:

• Is suitable for rules that cover inbound or outbound traffic.
• Supports regional scope.
• Is usable in Azure Firewall rules as a destination rule only for inbound or outbound traffic.

By default, service tags reflect the ranges for the entire cloud. Some service tags also allow more granular control by restricting the corresponding IP ranges to a specified region. For example, the service tag Storage represents Azure Storage for the entire cloud, but Storage.WestUS narrows the range to only the storage IP address ranges from the WestUS region. The following table indicates whether each service tag supports such regional scope, and the direction listed for each tag is a recommendation. For example, the AzureCloud tag might be used to allow inbound traffic. In most scenarios, we don't recommend allowing traffic from all Azure IPs since IPs used by other Azure customers are included as part of the service tag.

Tag	Purpose	Can use inbound or outbound?	Can be regional?	Can use with Azure Firewall?
ActionGroup	Action Group.	Inbound	No	Yes
ApiManagement	Management traffic for Azure API Management-dedicated deployments. Note: This tag represents the Azure API Management service endpoint for control plane per region. The tag enables customers to perform management operations on the APIs, Operations, Policies, NamedValues configured on the API Management service.	Inbound	Yes	Yes
ApplicationInsightsAvailability	Application Insights Availability.	Inbound	No	Yes
AppConfiguration	App Configuration.	Outbound	No	Yes
AppService	Azure App Service. This tag is recommended for outbound security rules to web apps and function apps. Note: This tag doesn't include IP addresses assigned when using IP-based SSL (App-assigned address).	Outbound	Yes	Yes
AppServiceManagement	Management traffic for deployments dedicated to App Service Environment.	Both	No	Yes
AzureActiveDirectory	Microsoft Entra ID Services. This tag includes sign-in, MS Graph and other Microsoft Entra services not listed in this table	Outbound	No	Yes
AzureActiveDirectoryDomainServices	Management traffic for deployments dedicated to Microsoft Entra Domain Services.	Both	No	Yes
AzureAdvancedThreatProtection	Microsoft Defender for Identity.	Outbound	No	Yes
AzureArcInfrastructure	Azure Arc-enabled servers, Azure Arc-enabled Kubernetes, and Guest Configuration traffic. Note: This tag has a dependency on the AzureActiveDirectory,AzureTrafficManager, and AzureResourceManager tags.	Outbound	No	Yes
AzureAttestation	Azure Attestation.	Outbound	No	Yes
AzureBackup	Azure Backup. Note: This tag has a dependency on the Storage and AzureActiveDirectory tags.	Outbound	No	Yes
AzureBotService	Azure Bot Service.	Both	No	Yes
AzureCloud	All datacenter public IP addresses. This tag doesn't include IPv6.	Both	Yes	Yes
AzureCognitiveSearch	Azure AI Search. This tag specifies the IP ranges of the multitenant execution environments used by a search service for indexer-based indexing. Note: The IP of the search service itself isn't covered by this service tag. In the firewall configuration of your Azure resource, you should specify the service tag and also the specific IP address of the search service itself.	Inbound	No	Yes
AzureConnectors	This tag represents the IP addresses used for managed connectors that make inbound webhook callbacks to the Azure Logic Apps service and outbound calls to their respective services, for example, Azure Storage or Azure Event Hubs.	Both	Yes	Yes
AzureContainerRegistry	Azure Container Registry.	Outbound	Yes	Yes
AzureCosmosDB	Azure Cosmos DB.	Outbound	Yes	Yes
AzureDatabricks	Azure Databricks.	Both	No	Yes
AzureDataExplorerManagement	Azure Data Explorer Management.	Inbound	No	Yes
AzureDeviceUpdate	Device Update for IoT Hub.	Both	No	Yes
AzureDevOps	Azure DevOps.	Inbound	Yes	Yes
AzureDigitalTwins	Azure Digital Twins. Note: This tag or the IP addresses covered by this tag can be used to restrict access to endpoints configured for event routes.	Inbound	No	Yes
AzureEventGrid	Azure Event Grid.	Both	No	Yes
AzureFrontDoor.Frontend AzureFrontDoor.Backend AzureFrontDoor.FirstParty AzureFrontDoor.MicrosoftSecurity	Frontend service tag contains the IP addresses that clients use to reach Front Door. You can apply the AzureFrontDoor.Frontend service tag when you want to control the outbound traffic that can connect to services behind Azure Front Door. Backend service tag contains the IP addresses that Azure Front Door uses to access your origins. You can apply this service tag when you configure security for your origins. FirstParty and MicrosoftSecurity are special tags reserved for a select group of Microsoft services hosted on Azure Front Door. FirstParty service tag is only available in public cloud while the other service tags are available in public and government clouds.	Both	Yes	Yes
AzureHealthcareAPIs	The IP addresses covered by this tag can be used to restrict access to Azure Health Data Services.	Both	No	Yes
AzureInformationProtection	Azure Information Protection. Note: This tag has a dependency on the AzureActiveDirectory, AzureFrontDoor.Frontend and AzureFrontDoor.FirstParty tags.	Outbound	No	Yes
AzureIoTHub	Azure IoT Hub.	Outbound	Yes	Yes
AzureKeyVault	Azure Key Vault. Note: This tag has a dependency on the AzureActiveDirectory tag.	Outbound	Yes	Yes
AzureLoadBalancer	The Azure infrastructure load balancer. The tag translates to the virtual IP address of the host (168.63.129.16) where the Azure health probes originate. This only includes probe traffic, not real traffic to your backend resource. If you're not using Azure Load Balancer, you can override this rule.	Both	No	No
AzureMachineLearningInference	This service tag is used for restricting public network ingress in private network managed inferencing scenarios.	Inbound	No	Yes
AzureManagedGrafana	Azure Managed Grafana instance endpoint.	Outbound	No	Yes
AzureMonitor	Log Analytics, Application Insights, Azure Monitor Workspace, AzMon, and custom metrics (GiG endpoints). Note: For Azure Monitor agent, AzureResourceManager is also required. For Log Analytics agent, the Storage tag is also required. If Linux Log Analytics agents are used, GuestAndHybridManagement tag is also required. (The legacy Log Analytics agent is deprecated as of August 31, 2024.)	Outbound	No	Yes
AzureOpenDatasets	Azure Open Datasets. Note: This tag has a dependency on the AzureFrontDoor.Frontend and Storage tag.	Outbound	No	Yes
AzurePlatformDNS	The basic infrastructure (default) DNS service. You can use this tag to disable the default DNS. Be cautious when you use this tag. We recommend that you read Azure platform considerations. We also recommend that you perform testing before you use this tag.	Outbound	No	No
AzurePlatformIMDS	Azure Instance Metadata Service (IMDS), which is a basic infrastructure service. You can use this tag to disable the default IMDS. Be cautious when you use this tag. We recommend that you read Azure platform considerations. We also recommend that you perform testing before you use this tag.	Outbound	No	No
AzurePlatformLKM	Windows licensing or key management service. You can use this tag to disable the defaults for licensing. Be cautious when you use this tag. We recommend that you read Azure platform considerations. We also recommend that you perform testing before you use this tag.	Outbound	No	No
AzureResourceManager	Azure Resource Manager.	Outbound	No	Yes
AzureSentinel	Microsoft Sentinel.	Inbound	No	Yes
AzureSignalR	Azure SignalR.	Outbound	No	Yes
AzureSiteRecovery	Azure Site Recovery. Note: This tag has a dependency on the AzureActiveDirectory, AzureKeyVault, EventHub, GuestAndHybridManagement and Storage tags.	Outbound	No	Yes
AzureSphere	This tag or the IP addresses covered by this tag can be used to restrict access to Azure Sphere Security Services.	Both	No	Yes
AzureSpringCloud	Allow traffic to applications hosted in Azure Spring Apps.	Outbound	No	Yes
AzureStack	Azure Stack Bridge services. This tag represents the Azure Stack Bridge service endpoint per region.	Outbound	No	Yes
AzureTrafficManager	Azure Traffic Manager probe IP addresses. For more information on Traffic Manager probe IP addresses, see Azure Traffic Manager FAQ.	Inbound	No	Yes
AzureUpdateDelivery	The Azure Update Delivery service tag used for accessing Windows Updates is deprecated. Customers are advised to not take a dependency on this service tag and for customers already using it they are advised to migrate to one of the following options: Configure Azure Firewall for your Windows 10/11 devices as documented: • Manage connection endpoints for Windows 11 Enterprise • Manage connection endpoints for Windows 10 Enterprise, version 21H2 Deploy the Windows Server Update Services (WSUS) Plan deployment for updating Windows VMs in Azure then proceed to Step 2: Configure WSUS For more information, see Changes coming to the Azure Update Delivery service tag	Outbound	No	Yes
AzureWebPubSub	AzureWebPubSub	Both	Yes	Yes
BatchNodeManagement	Management traffic for deployments dedicated to Azure Batch.	Both	Yes	Yes
ChaosStudio	Azure Chaos Studio. Note: If you have enabled Application Insights integration on the Chaos Agent, the AzureMonitor tag is also required.	Both	No	Yes
CognitiveServicesFrontend	The address ranges for traffic for Foundry Tools frontend portals.	Both	No	Yes
CognitiveServicesManagement	The address ranges for traffic for Foundry Tools.	Both	No	Yes
DataFactory	Azure Data Factory	Both	Yes	Yes
DataFactoryManagement	Management traffic for Azure Data Factory.	Outbound	No	Yes
Dynamics365ForMarketingEmail	The address ranges for the marketing email service of Dynamics 365.	Both	Yes	Yes
Dynamics365BusinessCentral	This tag or the IP addresses covered by this tag can be used to restrict access from/to the Dynamics 365 Business Central Services.	Both	No	Yes
EOPExternalPublishedIPs	This tag represents the IP addresses used for Security & Compliance Center PowerShell. Refer to the Connect to Security & Compliance Center PowerShell using the EXO V2 module for more details.	Both	No	Yes
EventHub	Azure Event Hubs.	Outbound	Yes	Yes
GatewayManager	Management traffic for deployments dedicated to Azure VPN Gateway and Application Gateway.	Inbound	No	No
GuestAndHybridManagement	Azure Automation and Guest Configuration.	Outbound	No	Yes
HDInsight	Azure HDInsight.	Inbound	Yes	Yes
Internet	The IP address space that's outside the virtual network and reachable by the public internet. The address range includes the Azure-owned public IP address space.	Both	No	No
KustoAnalytics	Kusto Analytics.	Both	No	No
LogicApps	Logic Apps.	Both	No	Yes
LogicAppsManagement	Management traffic for Logic Apps.	Inbound	No	Yes
M365ManagementActivityApi	The Office 365 Management Activity API provides information about various user, admin, system, and policy actions and events from Office 365 and Microsoft Entra activity logs. Customers and partners can use this information to create new or enhance existing operations, security, and compliance-monitoring solutions for the enterprise. Note: This tag has a dependency on the AzureActiveDirectory tag.	Outbound	Yes	Yes
M365ManagementActivityApiWebhook	Notifications are sent to the configured webhook for a subscription as new content becomes available.	Inbound	Yes	Yes
MicrosoftAzureFluidRelay	This tag represents the IP addresses used for Azure Microsoft Fluid Relay Server. Note: This tag has a dependency on the AzureFrontDoor.Frontend tag.	Both	No	Yes
MicrosoftCloudAppSecurity	Microsoft Defender for Cloud Apps.	Both	No	Yes
MicrosoftDefenderForEndpoint	Microsoft Defender for Endpoint core services. Note: Devices need to be onboarded with streamlined connectivity and meet requirements in order to use this service tag. Defender for Endpoint/Server require more service tags, like OneDSCollector, to support all functionality. For more information, see Onboarding devices using streamlined connectivity for Microsoft Defender for Endpoint	Both	No	Yes
PowerBI	Power BI platform backend services and API endpoints.	Both	Yes	Yes
PowerPlatformInfra	This tag represents the IP addresses used by the infrastructure to host Power Platform services.	Both	Yes	Yes
PowerPlatformPlex	This tag represents the IP addresses used by the infrastructure to host Power Platform extension execution on behalf of the customer.	Both	Yes	Yes
PowerQueryOnline	Power Query Online.	Both	No	Yes
Scuba	Data connectors for Microsoft security products (Microsoft Sentinel, Defender, etc.).	Inbound	No	No
SerialConsole	Limit access to boot diagnostics storage accounts from only Serial Console service tag	Inbound	No	Yes
ServiceBus	Azure Service Bus traffic.	Outbound	Yes	Yes
ServiceFabric	Azure Service Fabric. Note: This tag represents the Service Fabric service endpoint for control plane per region. This enables customers to perform management operations for their Service Fabric clusters from their virtual network endpoint. (For example, https:// westus.servicefabric.azure.com).	Both	No	Yes
Sql	Azure SQL Database, Azure Database for MariaDB, and Azure Synapse Analytics. Note: This tag represents the service, but not specific instances of the service. For example, the tag represents the Azure SQL Database service, but not a specific SQL database or server. This tag doesn't apply to SQL managed instance.	Outbound	Yes	Yes
SqlManagement	Management traffic for SQL-dedicated deployments.	Both	No	Yes
Storage	Azure Storage. Note: This tag represents the service, but not specific instances of the service. For example, the tag represents the Azure Storage service, but not a specific Azure Storage account.	Outbound	Yes	Yes
StorageSyncService	Storage Sync Service.	Both	No	Yes
StorageMover	Storage Mover.	Outbound	Yes	Yes
SystemServiceAzureSpringAppsResourceProvider	Azure Spring Apps. This tag represents the IP addresses used for Azure Spring Apps Resource Provider outbound traffic.	Inbound	Yes	Yes
WindowsAdminCenter	Allow the Windows Admin Center backend service to communicate with customers' installation of Windows Admin Center.	Outbound	No	Yes
WindowsVirtualDesktop	Azure Virtual Desktop (formerly Windows Virtual Desktop).	Both	No	Yes
VideoIndexer	Video Indexer. Used to allow customers opening up their NSG to Video Indexer service and receive callbacks to their service.	Both	No	Yes
VirtualNetwork	The virtual network address space (all IP address ranges defined for the virtual network), all connected on-premises address spaces, peered virtual networks, virtual networks connected to a virtual network gateway, the virtual IP address of the host, and address prefixes used on user-defined routes. This tag might also contain default routes.	Both	No	No

Note

• When using service tags with Azure Firewall, you can only create destination rules on inbound and outbound traffic. Source rules aren't supported. For more information, see the Azure Firewall Service Tags documentation.

• Service tags of Azure services denote the address prefixes from the specific cloud being used. For example, the underlying IP ranges that correspond to the Sql tag value on the Azure Public cloud are different from the underlying ranges on the Microsoft Azure operated by 21Vianet cloud.

• If you implement a virtual network service endpoint for a service, such as Azure Storage or Azure SQL Database, Azure adds a route to a virtual network subnet for the service. The address prefixes in the route are the same address prefixes, or CIDR ranges, as those of the corresponding service tag.

Tags unsupported for user defined routes (UDR)

The following list of tags is currently unsupported for use with user defined routes (UDR).

• AzurePlatformDNS
• AzurePlatformIMDS
• AzurePlatformLKM
• VirtualNetwork
• AzureLoadBalancer
• Internet

Service tags on-premises

You can obtain the current service tag and range information to include as part of your on-premises firewall configurations. This information is the current point-in-time list of the IP ranges that correspond to each service tag. You should obtain the information programmatically or via a JSON file download, as described in the following sections.

Use the Service Tag Discovery API

You can programmatically retrieve the current list of service tags together with IP address range details:

• REST
• Azure PowerShell
• Azure CLI

For example, to retrieve all the prefixes for the Storage Service Tag, you can use the following PowerShell cmdlets:

$serviceTags = Get-AzNetworkServiceTag -Location eastus2
$storage = $serviceTags.Values | Where-Object { $_.Name -eq "Storage" }
$storage.Properties.AddressPrefixes

Note

• The API data represents those tags that can be used with NSG rules in your region. Use the API data as the source of truth for available Service Tags as it might be different than the JSON downloadable file.
• It takes up to four weeks for new Service Tag data to propagate in the API results across all Azure regions. Because of this process, your API data results might be out of sync with the downloadable JSON file as the API data represents a subset of the tags currently in the downloadable JSON file.
• You must be authenticated and have a role with read permissions for your current subscription.

Discover service tags by using downloadable JSON files

You can download JSON files that contain the current list of service tags together with IP address range details. These lists are updated and published weekly. Locations for each cloud are.

• Azure Public
• Azure US Government
• Microsoft Azure operated by 21Vianet
• Azure Germany

The IP address ranges in these files are in CIDR notation.

The following AzureCloud tags don't have regional names formatted according to the normal schema:

• AzureCloud.centralfrance (FranceCentral)
• AzureCloud.southfrance (FranceSouth)
• AzureCloud.germanywc (GermanyWestCentral)
• AzureCloud.germanyn (GermanyNorth)
• AzureCloud.norwaye (NorwayEast)
• AzureCloud.norwayw (NorwayWest)
• AzureCloud.switzerlandn (SwitzerlandNorth)
• AzureCloud.switzerlandw (SwitzerlandWest)
• AzureCloud.usstagee (EastUSSTG)
• AzureCloud.usstagec (SouthCentralUSSTG)
• AzureCloud.brazilse (BrazilSoutheast)

Tip

• You can detect updates from one publication to the next by noting increased changeNumber values in the JSON file. Each subsection (for example, Storage.WestUS) has its own changeNumber that's incremented as changes occur. The top level of the file's changeNumber is incremented when any of the subsections is changed.
• For examples of how to parse the service tag information (for example, get all address ranges for Storage in WestUS), see the Service Tag Discovery API PowerShell documentation.
• When new IP addresses are added to service tags, they aren't used in Azure for at least one week. This process gives you time to update any systems that might need to track the IP addresses associated with service tags.
