Automating NetBox IP Address Inventory with Paginated REST API Calls

The problem: manual IP audits don’t scale

NetBox’s UI is great for ad‑hoc lookups, but when you need a full inventory across dozens of sites the click‑through approach becomes a time sink and a source of errors. The REST API lets you pull every IP address programmatically, and the built‑in cursor pagination makes it practical even for large deployments.

API basics you need to know

• Endpoint: /api/ipam/ip-addresses/ returns a JSON object with count, next, previous and a results array.
• Authentication: a token header Authorization: Token <your‑api‑token>. Create a read‑only token in NetBox → Admin → API Tokens and store it in an environment variable (e.g., NETBOX_TOKEN).
• Page size: default is 50 records; you can raise it with ?limit=200 but the next link will always reflect the server‑side limit.

Walking the pagination chain

The first request returns a next URL when more pages exist. A simple loop follows that URL until it becomes null. Each iteration appends the page’s results to a local list or streams them directly to disk.

import os, requests, csv, time

BASE = "https://netbox.example.com/api/ipam/ip-addresses/"
HEADERS = {"Authorization": f"Token {os.getenv('NETBOX_TOKEN')}"}
PARAMS = {"limit": 200}  # optional, reduces round‑trips

def fetch_all():
    url = BASE
    while url:
        resp = requests.get(url, headers=HEADERS, params=PARAMS if url == BASE else None)
        if resp.status_code == 429:          # rate limit
            retry = int(resp.headers.get("Retry-After", "5"))
            time.sleep(retry)
            continue
        resp.raise_for_status()
        data = resp.json()
        yield from data["results"]
        url = data["next"]

Run the generator from a script or REPL; it yields one IP‑address record at a time, keeping memory usage low.

Handling rate limits gracefully

NetBox enforces a configurable request‑per‑minute quota. The example above respects 429 Too Many Requests by reading the Retry-After header (or falling back to 5 seconds) and retrying. For production you may want exponential back‑off and a maximum retry count.

Worked example: CSV inventory report

The following script writes address, device, vrf, role and description to ip_inventory.csv. It prints progress every 1 000 records so you can monitor long runs.

#!/usr/bin/env python3
import os, csv, sys
import requests

def main():
    token = os.getenv("NETBOX_TOKEN")
    if not token:
        sys.exit("Set NETBOX_TOKEN environment variable")
    headers = {"Authorization": f"Token {token}"}
    url = "https://netbox.example.com/api/ipam/ip-addresses/"
    params = {"limit": 200}
    out_path = "ip_inventory.csv"
    fields = ["address", "device", "vrf", "role", "description"]

    with open(out_path, "w", newline="") as f:
        writer = csv.DictWriter(f, fieldnames=fields)
        writer.writeheader()
        count = 0
        while url:
            resp = requests.get(url, headers=headers, params=params if url == "https://netbox.example.com/api/ipam/ip-addresses/" else None)
            if resp.status_code == 429:
                wait = int(resp.headers.get("Retry-After", "5"))
                print(f"Rate limited, sleeping {wait}s")
                time.sleep(wait)
                continue
            resp.raise_for_status()
            data = resp.json()
            for rec in data["results"]:
                row = {
                    "address": rec["address"],
                    "device": rec["device"]["name"] if rec["device"] else "",
                    "vrf": rec["vrf"]["name"] if rec["vrf"] else "global",
                    "role": rec["role"]["name"] if rec["role"] else "",
                    "description": rec["description"] or ""
                }
                writer.writerow(row)
                count += 1
                if count % 1000 == 0:
                    print(f"Written {count} records…")
            url = data["next"]
    print(f"Done. {count} IP addresses exported to {out_path}")

if __name__ == "__main__":
    main()

Where to run: any host with Python 3.8+ and the requests library (pip install requests). The script needs network access to the NetBox API endpoint and the NETBOX_TOKEN env var set to a read‑only token.

Trade‑offs and limitations

• Volume: Very large installations (hundreds of thousands of IPs) can still produce sizable CSV files. Stream to disk (as shown) rather than accumulating in memory.
• Token scope: A token with write permissions is a security risk if leaked. Always generate a read‑only token and rotate it periodically.
• API version drift: Field names (e.g., device vs assigned_object) can change between NetBox releases. Pin the script to a tested NetBox version (v3.5+ at time of writing) and add a version check if you upgrade.

Verify the output

1. Run the script against a local NetBox demo (Docker Compose from the official repo).
2. Compare the CSV row count (excluding header) with the count field from the first API response; they should match.
3. Spot‑check a few entries in the NetBox UI under IPAM → IP Addresses to confirm field mapping.

Next steps

Schedule the script via cron or a CI job during off‑peak hours, compress the CSV (gzip ip_inventory.csv) and ship it to your CMDB or audit pipeline. If you need richer data (prefixes, VLANs, custom fields), extend the field list and adjust the extraction logic accordingly.
