Automate UI‑Data Sync in Delphi with LiveBindings

The problem: manual data‑binding boilerplate

In a typical VCL or FMX application you write OnChange, OnExit, or AfterScroll handlers to push values between edits, grids, and a TDataSet. That code is repetitive, error‑prone, and hard to maintain when the UI grows.

Useful takeaway

LiveBindings replaces those handlers with a declarative binding graph. A TBindingsList owns TBinding objects that connect a TBindingSource (wrapping a dataset field) to a visual control. The framework propagates changes in both directions, handles formatting, and validates input without you writing a single event.

Core mechanism

Components you’ll use

• TClientDataSet – in‑memory dataset (or any TDataSet descendant).
• TBindingsList – container that manages the lifetime of all bindings on a form.
• TBindingSource – adapter that exposes a dataset field as a bindable source.
• TDBText, TEdit, TComboBox, etc. – target controls that implement IBindableComponent.

Designer‑driven setup (fastest for prototypes)

1. Create a new Delphi VCL project (RAD Studio 11 Alexandria or later).
2. Drop a TClientDataSet (cdsPeople), add a field Name (string), and call CreateDataSet.
3. Place a TBindingsList (BindingsList1) on the form.
4. Add a TDBText (DBTextName) where you want the name displayed.
5. Open the LiveBindings Designer (View → LiveBindings Designer), drag from cdsPeople.FieldByName('Name') to DBTextName.Caption. The designer creates a TLinkControlToField binding automatically.
6. Run the application. Edit the dataset programmatically (e.g., cdsPeople.Edit; cdsPeople.FieldByName('Name').AsString := 'Alice'; cdsPeople.Post;) and the TDBText updates instantly.

Code‑level binding (explicit, version‑controlled)

When you need the binding in a non‑visual module or want to avoid the designer, create it in FormCreate:

uses
  System.Bindings.Helper, Data.Bind.Components, Data.Bind.DBScope;

procedure TForm1.FormCreate(Sender: TObject);
var
  Src: TBindingSource;
  Bind: TBinding;
begin
  // Ensure the dataset is active
  cdsPeople.CreateDataSet;
  cdsPeople.Open;

  // Wrap the field in a binding source
  Src := TBindingSource.Create(Self);
  Src.DataSet := cdsPeople;
  Src.DataField := 'Name';

  // Create a two‑way link between the source and the DBText.Caption property
  Bind := TBindingsList1.Bindings.Add(TBinding.Create(Src, DBTextName, 'Caption'));
  // Optional: add formatting/validation via Bind.Expression
end;

procedure TForm1.FormDestroy(Sender: TObject);
begin
  // Explicit cleanup prevents memory leaks
  BindingsList1.Free;
  // TBindingSource owned by the form is freed automatically
end;

Where to run: In the form’s unit, with System.Bindings.Helper, Data.Bind.Components, Data.Bind.DBScope in the uses clause. Requires no elevated permissions; runs in the main UI thread.

Expected check: After cdsPeople.FieldByName('Name').AsString := 'Bob'; the DBTextName.Caption shows "Bob" without any event code.

Risk: If you forget to free BindingsList1 (or the form’s TBindingSource instances) you leak the binding graph. Always free in FormDestroy or use an interface‑based owner.

Limits and when to avoid LiveBindings

Performance with large data sets

LiveBindings evaluates expressions on every change notification. With thousands of rows or complex calculated fields the UI thread can stall. For high‑volume grids or real‑time feeds, bind only the visible row or switch to manual OnGetText/OnSetText handling.

Memory management

Each TBinding and TBindingSource holds references to both the dataset and the control. Circular references are broken only when the TBindingsList is destroyed. In long‑lived forms (e.g., a main window that stays open) this is fine; in dynamically created/destroyed frames you must call BindingsList.Free explicitly.

Complex expressions and validation

The designer supports simple property‑to‑field links. For multi‑field calculations, conditional formatting, or cross‑control validation you must write custom TBindingExpression subclasses – which defeats the low‑code benefit. In those cases a dedicated presenter/view‑model layer is cleaner.

Common mistakes

• Binding to a closed dataset: The source field must be active (DataSet.Active := True) before the binding is added.
• Using the wrong property name: TDBText binds to Caption, TEdit to Text. Check the control’s IBindableComponent implementation.
• Leaving orphan bindings in frames: When a frame is freed, its TBindingsList must be freed first; otherwise the parent form’s binding list retains dangling references.

Practical verification steps

1. Build and run the VCL project described above.
2. In the debugger, pause after cdsPeople.Post and inspect DBTextName.Caption – it should match the dataset value.
3. Change the dataset field again via code (no UI interaction) and confirm the control updates.
4. Close the form; verify no memory‑leak report appears (enable ReportMemoryLeaksOnShutdown := True in the project source).

Version assumptions

LiveBindings is built‑in from RAD Studio 11 (Delphi 11 Alexandria) onward. Versions 10.4 and earlier required the separate LiveBindings package installation. The code example compiles under Delphi 11, 12, and 13 with the standard VCL library.
