Attach a cross-subscription backend to an Azure Load Balancer

In this article, you learn how to attach a cross-subscription backend to an Azure Load Balancer by creating a cross-subscription backend pool and attaching cross-subscription network interfaces to the backend pool of the load balancer.

A cross-subscription load balancer can reference a virtual network that resides in a different subscription other than the load balancers. This feature allows you to deploy a load balancer in one subscription and reference a virtual network in another subscription.

Prerequisites

• Azure PowerShell
• Azure CLI

• Two Azure subscriptions.
• An Azure account with active subscriptions. Create an account for free
• An existing Virtual Network. deployed in one of the subscriptions. For this example, the virtual network is in Azure Subscription A.
• Azure PowerShell installed locally or Azure Cloud Shell.

If you choose to install and use PowerShell locally, this article requires the Azure PowerShell module version 5.4.1 or later. Run Get-Module -ListAvailable Az to find the installed version. If you need to upgrade, see Install Azure PowerShell module. If you're running PowerShell locally, you also need to run Connect-AzAccount to create a connection with Azure.

Important

All of the code samples will use example names and placeholders. Be sure to replace these with the values from your environment. The values needing replacement will be enclosed in angle brackets, like this: <example value>.

• Two Azure subscriptions. One subscription for the virtual network (Azure Subscription A) and another subscription for the load balancer(Azure Subscription B).
• An Azure account with active subscriptions. Create an account for free
• An existing Virtual Network. deployed in one of the subscriptions. For this example, the virtual network is in Azure Subscription A.

• Use the Bash environment in Azure Cloud Shell. For more information, see Get started with Azure Cloud Shell.

  Open diagram: Documentation illustration

• If you prefer to run CLI reference commands locally, install the Azure CLI. If you're running on Windows or macOS, consider running Azure CLI in a Docker container. For more information, see How to run the Azure CLI in a Docker container.

  • If you're using a local installation, sign in to the Azure CLI by using the az login command. To finish the authentication process, follow the steps displayed in your terminal. For other sign-in options, see Authenticate to Azure using Azure CLI.

  • When you're prompted, install the Azure CLI extension on first use. For more information about extensions, see Use and manage extensions with the Azure CLI.

  • Run az version to find the version and dependent libraries that are installed. To upgrade to the latest version, run az upgrade.

If you choose to install and use the CLI locally, this quickstart requires Azure CLI version 2.60 or later. To find the version, run az --version. If you need to install or upgrade, see Install the Azure CLI.

Important

All of the code samples will use example names and placeholders. Be sure to replace these with the values from your environment. The values needing replacement will be enclosed in angle brackets, like this: <example value>.

Sign in to Azure

• Azure PowerShell
• Azure CLI

With Azure PowerShell, you sign into Azure with Connect-AzAccount, and change your subscription context with Set-AzContext to Azure Subscription A. Then get the virtual network information with Get-AzVirtualNetwork. You need the Azure subscription ID, resource group name, and virtual network name from your environment.

# Sign in to Azure
Connect-AzAccount

# Set the subscription context to Azure Subscription A
Set-AzContext -Subscription '<Azure Subscription A>'

# Get the Virtual Network information with Get-AzVirtualNetwork
$net = @{
    Name = 'virtual-network-subA'
    ResourceGroupName = 'resource-group-v2'
}
$vnet = Get-AzVirtualNetwork @net

With Azure CLI, you'll sign into Azure with [az login](/cli/azure/reference-index#az-login), and change your subscription context with [`az account set`](/cli/azure/account#az_account_set) to **Azure Subscription A**.

```azurecli

# Sign in to Azure CLI and change subscription to Azure Subscription A
Az login
Az account set –subscription <Azure Subscription A>

Create a resource group

In this section, you create a resource group in Azure Subscription B. This resource group is for all of your resources associate with your load balancer.

• Azure PowerShell
• Azure CLI

With Azure PowerShell, you switch the subscription context with Set-AzContext and create a resource group with New-AzResourceGroup.

# Set the subscription context to Azure Subscription B
Set-AzContext -Subscription '<Azure Subscription B>'

# Create a resource group
$rg = @{
    Name = 'myResourceGroupLB'
    Location = 'westus'
}
New-AzResourceGroup @rg

Note

When create the resource group for your load balancer, use the same Azure region as the virtual network in Azure Subscription A.

With Azure CLI, you switch the subscription context with az account set and create a resource group with az group create.

# Create a resource group in Azure Subscription B
az group create --name 'myResourceGroupLB' --location westus

Note

When create the resource group for your load balancer, use the same Azure region as the virtual network in Azure Subscription A.

Create a load balancer

In this section, you create a load balancer in Azure Subscription B. You create a load balancer with a frontend IP address.

• Azure PowerShell
• Azure CLI

With Azure PowerShell, you'll:

• A load balancer with New-AzLoadBalancer
• Create a public IP address with New-AzPublicIpAddress
• Add a frontend IP configuration with Add-AzLoadBalancerFrontendIpConfig
• Create a backend address pool with New-AzLoadBalancerBackendAddressPool.

# Create a load balancer
$loadbalancer = @{
    ResourceGroupName = 'resource group B'
    Name = 'LB Name'
    Location = 'eastus'
    Sku = 'Standard'
}
$LB = New-AzLoadBalancer @loadbalancer

$LBinfo = @{
    ResourceGroupName = 'resource group B'
    Name = 'my-lb'
}

# Create a public IP address
$publicip = @{
    Name = 'IP Address Name'
    ResourceGroupName = 'resource group B'
    Location = 'eastus'
    Sku = 'Standard'
    AllocationMethod = 'static'
    Zone = 1,2,3
}
New-AzPublicIpAddress @publicip


# Place public IP created in previous steps into variable
$pip = @{
    Name = 'IP Address Name'
    ResourceGroupName = 'resource group B'
}
$publicIp = Get-AzPublicIpAddress @pip

## Create load balancer frontend configuration and place in variable
$fip = @{
    Name = 'Frontend Name'
    PublicIpAddress = $publicip
}
$LB = $LB | Add-AzLoadBalancerFrontendIpConfig @fip
$LB = $LB | Set-AzLoadBalancer

# Create backend address pool configuration and place in variable. ##

$be = @{
    ResourceGroupName= "resource group B"
    Name= "myBackEndPool"
    LoadBalancerName= "LB Name"
    VirtualNetwork=$vnet.id
    SyncMode= "Automatic"
}

#Create the backend pool
$backend = New-AzLoadBalancerBackendAddressPool @be
$LB = Get-AzLoadBalancer @LBinfo

With Azure CLI, you create a load balancer with az network lb create and update the backend pool. This example configures the following resources:

• A frontend IP address that receives the incoming network traffic on the load balancer.
• A backend address pool where the frontend IP sends the load balanced network traffic.

# Create a load balancer
az network lb create --resource-group myResourceGroupLB --name myLoadBalancer --sku Standard --public-ip-address myPublicIP   --frontend-ip-name myFrontEnd --backend-pool-name BackendPool1 --tags 'IsRemoteFrontend=true'

In order to utilize the cross-subscription feature of Azure load balancer, backend pools need to have the syncMode property enabled and a virtual network reference. This section updates the backend pool created prior by attaching the cross-subscription virtual network and enabling the syncMode property.

## Configure the backend address pool and syncMode property
az network lb address-pool update --lb-name myLoadBalancer --resource-group myResourceGroupLB -n myResourceGroupLB --vnet ‘/subscriptions/<subscription A ID>/resourceGroups/{resource group name}/providers/Microsoft.Network/virtualNetwork/{VNet name}’ --sync-mode Automatic

Create a health probe and load balancer rule

Create a health probe that determines the health of the backend VM instances and a load balancer rule that defines the frontend IP configuration for the incoming traffic, the backend IP pool to receive the traffic, and the required source and destination port.

• Azure PowerShell
• Azure CLI

With Azure PowerShell, create a health probe with Add-AzLoadBalancerProbeConfig that determines the health of the backend VM instances. Then create a load balancer rule with Add-AzLoadBalancerRuleConfig that defines the frontend IP configuration for the incoming traffic, the backend IP pool to receive the traffic, and the required source and destination port.

## Create the health probe and place in variable. ##
$probe = @{
    Name = 'myHealthProbe2'
    Protocol = 'tcp'
    Port = '80'
    IntervalInSeconds = '360'
    ProbeCount = '5'
}

## Create the load balancer rule and place in variable. ##
$lbrule = @{
    Name = 'myHTTPRule2'
    Protocol = 'tcp'
    FrontendPort = '80'
    BackendPort = '80'
    IdleTimeoutInMinutes = '15'
    FrontendIpConfiguration = $LB.FrontendIpConfigurations[0]
    BackendAddressPool = $backend
}
## Set the load balancer resource. ##
$LB | Add-AzLoadBalancerProbeConfig @probe
$LB | Add-AzLoadBalancerRuleConfig  @lbrule
$LB | Set-AzLoadBalancer

With Azure CLI, create a health probe with az network lb probe create that determines the health of the backend VM instances. Then create a load balancer rule with az network lb rule create that defines the frontend IP configuration for the incoming traffic, the backend IP pool to receive the traffic, and the required source and destination port.

# Create a health probe
az network lb probe create --resource-group myResourceGroupLB --lb-name myLoadBalancer --name myHealthProbe --protocol tcp --port 80

# Create a load balancer rule
az network lb rule create --resource-group myResourceGroupLB --lb-name myLoadBalancer --name myHTTPRule --protocol tcp --frontend-port 80 --backend-port 80 --frontend-ip-name myFrontEnd --backend-pool-name myBackEndPool --probe-name myHealthProbe --disable-outbound-snat true --idle-timeout 15 --enable-tcp-reset true

Attach network interface cards to the load balancer

• Azure PowerShell
• Azure CLI

In this section, you attach the network interface card (NIC) in Azure Subscription A to the load balancer in Azure Subscription B. You create a network interface with New-AzNetworkInterface and then create an IP configuration for the network interface card with New-AzNetworkInterfaceIpConfig.

Note

The network interface card (NIC) must be in the same VNet as the load balancer’s backend pool.

# Set the subscription context to **Azure Subscription A**
Set-AzContext -Subscription 'Sub A'

# Create a network interface card
$IP1 = @{
    Name = 'MyIpConfig'
    subnetID= $vnet.subnets[0].Id
    PrivateIpAddressVersion = 'IPv4'
}
$IP1Config = New-AzNetworkInterfaceIpConfig @IP1 -Primary
$nic = @{
    Name = 'MyNic'
    ResourceGroupName = '<Resource Group Subscription A>'
    Location = 'eastus'
    IpConfiguration = $IP1Config
    LoadBalancerBackendAddressPool = "/subscriptions/<Subscription B ID>/resourceGroups/myResourceGroupLB/providers/Microsoft.Network/loadBalancers/myLoadBalancer/backendAddressPools/BackendPool1"
}
New-AzNetworkInterface @nic

In this section, you attach the network interface card (NIC) in Azure Subscription A to the load balancer in Azure Subscription B with az network nic create

Note

The network interface card (NIC) must be in the same VNet as the load balancer’s backend pool.

# Set the subscription context to **Azure Subscription A**
Az account set –subscription 'Sub A'

# Attach the network interface card to the load balancer
az network nic create --name NIC --resource-group NIC-rg --vnet VNET-name --lb-address-pool "/subscriptions/<Subscription B ID>/resourceGroups/myResourceGroupLB/providers/Microsoft.Network/loadBalancers/myLoadBalancer/backendAddressPools/BackendPool1"

Clean up resources

When no longer needed, you can use the Remove-AzResourceGroup command to remove the resource group you created along with the load balancer, and the remaining resources.

• Azure PowerShell
• Azure CLI

Remove-AzResourceGroup -Name 'myResourceGroupLB'

az group delete --name myResourceGroupLB
