Architecture Note: Using Prolog CLP(FD) for Deterministic Safety-Critical Configuration Solving

Requirements

The configuration subsystem must:

• Represent each configurable parameter as an integer variable with a known finite domain (e.g., 0‑10).
• Express arithmetic and logical constraints between those variables (equality, inequality, ordering).
• Return either a concrete assignment that satisfies all constraints or a clear unsatisfiability signal.
• Guarantee deterministic runtime behavior suitable for certification (no unbounded search, no nondeterministic side‑effects).
• Treat incoming configuration data as untrusted and prevent malicious values from causing domain explosions or infinite loops.

Smallest Suitable Design

A single Prolog module that imports the CLP(FD) library, defines domain variables, posts constraints using CLP(FD) arithmetic operators, and invokes labeling/2 to search for a solution meets the above requirements.

:- use_module(library(clpfd)).

solve_config(Params, Solution) :-
    % Params is a list of validated integer values supplied by the caller
    % Example: Params = [MaxSum, Switch1Max, Switch2Max, Switch3Max]
    [MaxSum, S1Max, S2Max, S3Max] = Params,

    % Domain variables for three switches
    Switch1 in 0..S1Max,
    Switch2 in 0..S2Max,
    Switch3 in 0..S3Max,

    % Constraint: total activation must not exceed MaxSum
    Switch1 + Switch2 + Switch3 #=< MaxSum,

    % Additional example constraint: Switch1 must be at least 1 if Switch2 is 2
    Switch2 #= 2 #==> Switch1 #>= 1,

    % Search for a solution
    labeling([ff], [Switch1, Switch2, Switch3]),

    % Build result structure
    Solution = [switch1=Switch1, switch2=Switch2, switch3=Switch3].

% Entry point for command‑line use
main :-
    current_prolog_flag(argv, [File|_]),
    file_exists(File) ->
        read_terms(File, Terms),
        mapcall(validate_and_solve, Terms) ;
    format('Usage: swipl -q -s solver.pl -g main -t halt -- \n'),
    halt(1).

validate_and_solve(Term) :-
    % Expect a term like config(MaxSum,S1Max,S2Max,S3Max)
    Term =.. [config|Vals],
    % Simple validation: all values must be integers in 0..100
    maplist(between(0,100), Vals),
    solve_config(Vals, Sol),
    format('Solution: ~w~n', [Sol]),
    fail; _ -> true.  % fail after first solution to demonstrate unsatisfiable handling

read_terms(File, Terms) :-
    open(File, read, Stream),
    read_terms(Stream, Terms, []),
    close(Stream).

mapcall(_, []).
mapcall(Pred, [H|T]) :-
    call(Pred, H),
    mapcall(Pred, T).

The module contains only pure predicates; no assert/1 or retract/1 appears inside the solving clause, preserving logical purity.

Trust / Data Boundaries

All data that originates outside the trusted core (e.g., configuration files, operator input) is first passed through a validation step:

• Values are checked to be integers.
• Each value is confined to a predefined safe range (here 0‑100).
• Only after validation are the values bound to CLP(FD) domain variables via in/2 or used as bounds for those variables.

This boundary prevents an attacker from supplying a huge domain (e.g., 0‑1_000_000) that could cause propagation to allocate excessive memory or drive the search space to infeasible size.

Operational Checks

At runtime the program performs three observable checks:

1. Validation result – if any input term fails the integer/range test, the solver skips that term and logs a validation warning.
2. Labeling outcome – labeling/2 either succeeds (returning a concrete assignment) or fails. Success triggers a secondary verification predicate that re‑evaluates each original constraint with the obtained values to ensure no propagation error slipped through.
3. Timeout guard (optional) – wrapping the call to labeling/2 with call_with_time_limit/2 (e.g., 500 ms) guarantees that a pathological constraint set cannot hang the system; on timeout the solver reports "search exceeded time limit" and treats the configuration as unsatisfiable for safety purposes.

These checks produce deterministic observable outcomes: a solution, a validation warning, a timeout notice, or an explicit unsatisfiability report.

Failure Modes

• Constraint overload / search blow‑up – highly constrained or poorly ordered variables can cause exponential search time. Mitigation: use variable ordering heuristics (ff – first fail) in labeling/2, apply iterative deepening, or enforce a timeout as described.
• Incomplete propagation for nonlinear constraints – CLP(FD) guarantees domain consistency only for linear constraints. Non‑linear expressions (e.g., X*Y #= Z) may leave spurious values in domains, requiring explicit enumeration (labeling/2) to eliminate them.
• Mixing impure predicates – inserting assert/1 or retract/1 inside the solving clause breaks referential transparency, making it harder to prove that a given input always yields the same output, which is undesirable for certification.

Conditions That Would Change the Design

The current design would be revisited if any of the following arose:

• Non‑integer domains – if configuration parameters needed to be floats or rational numbers, CLP(FD) would be insufficient; a switch to CLP(R) (real numbers) or an external SAT/SMT solver handling floating‑point theory would be required.
• Global optimization objectives – should the system need to minimize or maximize a cost function (e.g., power consumption) rather than merely find any feasible solution, a dedicated optimization library (labeling/2 with max/2 or min/2) or a mixed‑integer programming solver would be more appropriate.
• Higher‑throughput demands – if the configuration service must solve thousands of instances per second with sub‑millisecond latency, the overhead of Prolog’s backtracking might become prohibitive, prompting a move to a compiled constraint‑propagation engine or a SAT solver with incremental solving capabilities.
• Certification constraints requiring proof‑carrying code – some safety standards demand a machine‑checkable proof of correctness. In that case, generating a proof artifact from the CLP(FD) solving process (e.g., via proof‑producing SAT solvers) would be necessary, altering the interface from a simple solution return to a solution plus proof object.

Practical Verification Steps

To confirm that the solver behaves as intended:

1. Create a file sat.pl containing a known satisfiable configuration, e.g., config(5,2,2,2).
2. Run the solver: swipl -q -s solver.pl -g main -t halt -- sat.pl. Expected output: a line beginning with "Solution:" showing three numbers whose sum ≤ 5 and satisfying the extra implication constraint.
3. Create an unsatisfiable file unsat.pl with contradictory constraints, e.g., config(0,2,2,2). (sum must be ≤ 0 but each switch ≥ 0 and at least one must be ≥ 1 due to the implication when Switch2=2).
4. Run the same command with unsat.pl. The program should print no "Solution:" line and exit with code 0 after exhausting the search (or report a timeout if one is configured).
5. Optionally enable timing: swipl -q -s solver.pl -g "call_with_time_limit(main, 500)" -t halt -- unsat.pl and verify that the solver terminates within the limit.

These steps provide a concrete, repeatable way to validate both the satisfiable and unsatisfiable paths without relying on external benchmarks.
