Architecture Note: NuGet Package Restore in Automated Builds

The Problem: Non-Deterministic Restores

In automated build pipelines, relying on direct connections to public galleries like nuget.org introduces three primary risks: non-deterministic builds due to floating versions, pipeline failure during public gallery outages, and security vulnerabilities from dependency confusion or tampered packages. The goal is a restore process that is immutable, verified, and isolated.

Requirements

To ensure build stability and security, the restore architecture must satisfy these requirements:

• Reproducibility: The exact same package versions must be resolved across every build of a specific commit.
• Integrity: Packages must be verified via SHA512 hashes to ensure the binary has not been altered.
• Isolation: The build agent should not have unrestricted outbound access to the public internet for dependency resolution.
• Fail-Fast Behavior: Any mismatch in version, hash, or authentication must halt the pipeline immediately.

Smallest Suitable Design

The minimal design that meets these requirements is a Read-Only Mirror Architecture. Instead of the agent querying the public gallery, it queries an internal proxy or hosted repository (such as Azure Artifacts, Nexus, or Artifactory) that contains only vetted, approved packages.

Core Components

1. Build Agent: Executes the dotnet restore or MSBuild -t:Restore command.
2. Trusted Mirror: An internal feed acting as the single source of truth.
3. Global-Packages Folder: The local cache (%USERPROFILE%\.nuget\packages on Windows) where NuGet stores packages and their corresponding hash files.
4. Lock File (project.assets.json): A generated file that records the exact resolution graph and hashes for the project.

Configuration Example

The following NuGet.Config should be placed at the repository root. Note that the public gallery is explicitly disabled to prevent the agent from bypassing the mirror.

<configuration>
  <packageSources>
    <add key="InternalMirror" value="https://company.pkgs.visualstudio.com/_packaging/MainFeed/nuget/v3/index.json" />
  </packageSources>
  <disabledPackageSources>
    <add key="nuget.org" value="true" />
  </disabledPackageSources>
  <packageSourceCredentials>
    <InternalMirror>
      <username>build_service_account</username>
      <password>%NUGET_FEED_TOKEN%</password>
    </InternalMirror>
  </packageSourceCredentials>
</configuration>

Risk Note: Never commit plain-text tokens to source control. Use environment variable substitution (e.g., %NUGET_FEED_TOKEN%) injected by your CI provider's secret manager.

Trust and Data Boundaries

The trust boundary is strictly defined by the <packageSources> section. Any source not explicitly listed or specifically enabled is treated as untrusted. Data flows as follows:

• The agent reads NuGet.Config to identify the trusted endpoint.
• NuGet requests metadata and the .nupkg file from the mirror.
• The downloaded package is verified against the SHA512 hash. If the hash does not match the one recorded in the lock file or the global-packages folder, the process terminates.
• The project.assets.json file is updated only after successful verification.

Operational Checks

To verify the implementation on a clean build agent, perform these checks:

1. Network Isolation: Run dotnet restore and monitor network logs to ensure no traffic is sent to nuget.org.
2. Cache Audit: Inspect the global-packages folder and verify that the .nupkg.sha512 files exist for all restored dependencies.
3. Exit Code: Ensure the restore command returns exit code 0. Any non-zero exit must trigger a pipeline failure.

Failure Modes

NuGet provides specific error codes that allow the pipeline to diagnose the failure point quickly:

Error Code	Condition	Root Cause
NU1107	Version Conflict	Incompatible version ranges requested by different projects.
NU1605	Hash Mismatch	The package binary was altered or corrupted on the mirror.
NU1301	Auth Failure	The agent's token is expired or lacks permissions for the mirror.

Conditions for Redesign

This architecture should be re-evaluated if:

• Poly-repo Scaling: The organization moves to a structure where teams require autonomous, external pre-release packages that cannot be mirrored centrally.
• Toolchain Migration: The project migrates to a build system (e.g., Bazel) that does not use the MSBuild restore target.
• Latency Constraints: Mirror latency becomes a critical bottleneck, necessitating a hybrid approach with strict hash-locking for external sources.

Practical Verification: Testing Integrity

To confirm that the system prevents tampered packages from entering the build, simulate a corruption event:

1. Download a vetted package from the mirror.
2. Modify a single byte within the package's DLL.
3. Upload the modified package back to the mirror (or a test feed) while keeping the original hash in the project.assets.json lock file.
4. Run dotnet restore. The build must fail with NU1605.

Limitations

A trusted mirror prevents external tampering but does not protect against a compromised package that was vetted and uploaded to the mirror originally. This requires complementary vulnerability scanning (SCA). Additionally, to prevent silent updates from floating versions (e.g., 1.0.*), use the --locked-mode flag (available in .NET 6+ SDK):

dotnet restore --locked-mode

This ensures that if the lock file needs to be updated to resolve a dependency, the restore fails rather than silently updating the version.
