Angular HttpClient Interceptor: Centralizing Cross‑Cutting Concerns

Requirements

Applications often need to apply the same logic to every HTTP request made with HttpClient: attaching an authentication token, logging errors, or transforming request/response payloads. Duplicating this code in each service leads to maintenance overhead and increases the chance of inconsistencies.

Smallest Suitable Design

The Angular HttpInterceptor interface lets you insert a piece of code into the HTTP pipeline. By creating a single class that implements HttpInterceptor and registering it in the root module’s providers array with multi: true, Angular’s dependency‑injection chain will invoke the interceptor for every HttpClient instance.

Trust/Data Boundaries

Treat the interceptor as a trusted boundary:

• For outgoing requests, it can safely add headers (e.g., an auth token) because it runs before the request leaves the application.
• For incoming responses, it can centralize error handling or transformation, keeping service components unaware of these concerns.

Service code remains focused on domain logic; the interceptor handles cross‑cutting concerns.

Operational Checks

To verify the interceptor works:

• Unit test with HttpTestingController to assert that headers are added and that error responses are handled as expected.
• In a running application, open the browser’s network tab and confirm that requests contain the expected headers.
• Optionally, use Angular DevTools or custom logging inside the interceptor to ensure no request bypasses it.

Failure Modes

• If the interceptor throws an error, the observable chain fails and the error propagates to the subscriber.
• Omitting multi: true when providing the interceptor causes Angular to replace rather than append it, effectively ignoring the intended interceptor.
• Circular dependency injection (e.g., the interceptor depending on a service that itself uses HttpClient) can break the injector and cause a runtime error.

Conditions That Would Change the Design

• Need to skip the interceptor for certain endpoints (e.g., public API calls) would require adding a configuration option, such as a custom header or a flag in the request, and checking it inside the interceptor.
• When multiple independent interceptors with strict ordering are required, a factory provider that returns an array of interceptors in the desired sequence may be preferable to relying on implicit order.

Example Implementation

import { Injectable } from '@angular/core';
import {
  HttpEvent,
  HttpHandler,
  HttpInterceptor,
  HttpRequest,
} from '@angular/common/http';
import { Observable, throwError } from 'rxjs';
import { catchError } from 'rxjs/operators';

@Injectable()
export class AuthInterceptor implements HttpInterceptor {
  // In a real app, retrieve the token from a storage service.
  private getToken(): string | null {
    return localStorage.getItem('access_token');
  }

  intercept(
    req: HttpRequest,
    next: HttpHandler
  ): Observable> {
    const token = this.getToken();

    // Clone request and set the Authorization header if a token exists.
    let authReq = req;
    if (token !== null) {
      authReq = req.clone({
        setHeaders: { Authorization: `Bearer ${token}` },
      });
    }

    // Pass the cloned request to the next handler and catch any errors.
    return next.handle(authReq).pipe(
      catchError((error) => {
        // Centralized error handling: log and optionally redirect.
        console.error('HTTP error', error);
        // Re‑throw so subscribers can still react.
        return throwError(() => error);
      })
    );
  }
}

Module Registration

import { NgModule } from '@angular/core';
import { HTTP_INTERCEPTORS } from '@angular/common/http';
import { AuthInterceptor } from './auth.interceptor';

@NgModule({
  providers: [
    {
      provide: HTTP_INTERCEPTORS,
      useClass: AuthInterceptor,
      multi: true, // Important: adds to the chain rather than replacing.
    },
  ],
})
export class CoreModule {}

Verification Steps

1. Create a new Angular project: ng new interceptor-demo.
2. Generate the interceptor: ng generate interceptor auth (this creates the class skeleton).
3. Replace the generated code with the AuthInterceptor implementation above.
4. Provide the interceptor in AppModule or a dedicated CoreModule as shown.
5. Run the app: ng serve and open DevTools → Network. Perform an HTTP call (e.g., via a service) and verify that the Authorization header appears.
6. For unit testing, add a spec like:

import { TestBed } from '@angular/core/testing';
import {
  HttpClientTestingModule,
  HttpTestingController,
} from '@angular/common/http/testing';
import { AuthInterceptor } from './auth.interceptor';
import { HTTP_INTERCEPTORS, HttpClient } from '@angular/common/http';

describe('AuthInterceptor', () => {
  let httpMock: HttpTestingController;
  let http: HttpClient;

  beforeEach(() => {
    TestBed.configureTestingModule({
      imports: [HttpClientTestingModule],
      providers: [
        { provide: HTTP_INTERCEPTORS, useClass: AuthInterceptor, multi: true },
      ],
    });
    http = TestBed.inject(HttpClient);
    httpMock = TestBed.inject(HttpTestingController);
  });

  afterEach(() => {
    httpMock.verify();
  });

  it('should add Authorization header when token exists', () => {
    localStorage.setItem('access_token', 'test-token');

    http.get('/api/data').subscribe();

    const req = httpMock.expectOne('/api/data');
    expect(req.request.headers.has('Authorization')).toBeTrue();
    expect(req.request.headers.get('Authorization')).toBe('Bearer test-token');
    req.flush({}); // respond with empty body
  });

  it('should not add Authorization header when token missing', () => {
    localStorage.removeItem('access_token');

    http.get('/api/data').subscribe();

    const req = httpMock.expectOne('/api/data');
    expect(req.request.headers.has('Authorization')).toBeFalse();
    req.flush({});
  });
});

Limitations

• The interceptor runs for all HttpClient instances, including those used internally by Angular libraries (e.g., the Router when fetching navigation scripts). If you need to exclude certain calls, add a custom header or flag and check it inside the interceptor.
• Because interceptors execute outside the Angular zone, change detection is not triggered automatically after processing a response. If your interceptor updates UI‑relevant state, you may need to run the change detection manually (e.g., inject ApplicationRef and call tick()) or let the service layer handle UI updates.
