Adding PKCE to OAuth 2.0: A Step‑by‑Step Guide for Public Clients

Desired Outcome

Secure a public OAuth 2.0 client (mobile app, SPA, or console app) against authorization code interception by adding Proof Key for Code Exchange (PKCE). The result is a token request that the server can validate only if the original client presented the same verifier.

Prerequisites

• OAuth 2.0 authorization server that supports PKCE (most modern providers do).
• Client application codebase with network access to the /authorize and /token endpoints.
• Access to a cryptographic library for random bytes and SHA‑256 hashing.
• Secure temporary storage on the client (in‑memory, secure cookie, or platform‑specific keychain).

Generating the Code Verifier and Challenge

The code_verifier is a high‑entropy, 43–128 character string. The code_challenge is derived from it.

// Node.js example
const crypto = require('crypto');
const codeVerifier = crypto.randomBytes(32).toString('hex'); // 64‑char hex

// S256 transformation
const hash = crypto.createHash('sha256').update(codeVerifier).digest();
const codeChallenge = hash.toString('base64url');

Store codeVerifier securely until the token exchange. Do not log it.

Modifying the Authorization Request

Include the challenge and its method in the query string:

GET https://auth.example.com/authorize?
  client_id=YOUR_CLIENT_ID
  &response_type=code
  &redirect_uri=https%3A%2F%2Fapp.example.com%2Fcallback
  &code_challenge=CODE_CHALLENGE
  &code_challenge_method=S256

Replace CODE_CHALLENGE with the value from the previous step. If you choose the plain method, omit the hash step and set code_challenge_method=plain, but S256 is strongly recommended.

Token Exchange with the Verifier

When the user authorizes, the server redirects to your redirect_uri with a code. Exchange it for tokens, sending the original code_verifier:

POST https://auth.example.com/token
Content-Type: application/x-www-form-urlencoded

grant_type=authorization_code
&code=AUTHORIZATION_CODE
&redirect_uri=https%3A%2F%2Fapp.example.com%2Fcallback
&client_id=YOUR_CLIENT_ID
&code_verifier=CODE_VERIFIER

The authorization server hashes the received code_verifier (if S256 was used) and compares it to the stored challenge. Mismatch results in invalid_grant.

Expected Checks & Validation

• The code_challenge parameter must be present in the initial request.
• The server must return 400 Bad Request if code_challenge is missing.
• After token exchange, the server should return an access_token only if the verifier matches.
• Verify the token’s iss and aud claims match your configuration.

Common Pitfalls & Recovery

• Verifier lost or overwritten – the flow fails. Keep the verifier in a single, short‑lived storage scope.
• Using plain method with weak verifier – increases risk. Prefer S256.
• Logging the verifier – expose secrets. Strip from logs and monitoring.
• Server not supporting PKCE – check the provider’s documentation or use the response_type=code flow without PKCE.

Example Implementation (Express + Passport)

Below is a minimal Express route that initiates PKCE and handles the callback. Replace placeholders with your own values.

const express = require('express');
const crypto = require('crypto');
const fetch = require('node-fetch');
const app = express();

app.get('/auth', (req, res) => {
  const codeVerifier = crypto.randomBytes(32).toString('hex');
  const codeChallenge = crypto.createHash('sha256').update(codeVerifier).digest().toString('base64url');

  // Store verifier in session or secure cookie
  req.session.codeVerifier = codeVerifier;

  const authUrl = `https://auth.example.com/authorize?` +
    new URLSearchParams({
      client_id: 'YOUR_CLIENT_ID',
      response_type: 'code',
      redirect_uri: 'https://app.example.com/callback',
      code_challenge: codeChallenge,
      code_challenge_method: 'S256'
    });
  res.redirect(authUrl);
});

app.get('/callback', async (req, res) => {
  const { code } = req.query;
  const codeVerifier = req.session.codeVerifier;
  if (!codeVerifier) return res.status(400).send('Missing verifier');

  const tokenResp = await fetch('https://auth.example.com/token', {
    method: 'POST',
    headers: { 'Content-Type': 'application/x-www-form-urlencoded' },
    body: new URLSearchParams({
      grant_type: 'authorization_code',
      code,
      redirect_uri: 'https://app.example.com/callback',
      client_id: 'YOUR_CLIENT_ID',
      code_verifier: codeVerifier
    })
  });
  const tokenData = await tokenResp.json();
  // Handle tokenData (store, use, etc.)
  res.send('Logged in');
});

app.listen(3000, () => console.log('App listening on 3000'));

Comparison: Plain vs S256

Method	Security Level	Implementation Complexity
plain	Low – verifier can be brute‑forced; vulnerable to interception.	None – no hashing required.
S256	High – SHA‑256 hash mitigates brute‑force and replay attacks.	Requires SHA‑256 support (most libraries provide it).

Testing the Flow

1. Run the example app locally and navigate to /auth.
2. Authorize the app in the browser; you should be redirected back to /callback.
3. Inspect the network tab for the /token POST request. Verify that code_verifier is present.
4. Use a tool like Postman to repeat the token request without code_verifier and confirm the server rejects it.
5. Check the token’s aud and iss claims match your client configuration.

Summary

PKCE turns the standard Authorization Code flow into a secure exchange for public clients. By generating a random verifier, deriving a challenge, and requiring the verifier at token exchange, you protect against interception and replay attacks with minimal code changes. Follow the steps above, choose the S256 method, and verify your provider’s support to keep your users safe.
